SCISSORDECK
Mobile Work Platforms

Our Original Product Line!

40 in wide model Scissor Deck 6000 series June 2022.jpg
40 in wide model  Powered Scissor Deck 6000 series June 2022 cropped med res.jpg
Scissor Deck color logo

Our original product line, Scissor Decks are connectable, height-adjustable and foldable aluminum work platforms with choice of wheels for mobility and with a multitude of applications across a wide range of industries.

​

These popular maintenance platforms are quick and easy to set up, fold flat for transport and storage, and enhance a safe and efficient work environment. The larger models are also available as powered versions.

​

Any of our Scissor Deck models can be easily transformed into Scissor Deck Systems, by bridging two or more Scissor Decks with connecting platforms resulting in safe and continuous walkways.

​

Explore our Scissor Deck product offerings below, or request a quote for a customized recommendation.

SCISSOR DECK PRODUCTS

Scissor Deck Wheeled Platforms

Looking for Stand Versions of Scissor Decks?

Check Out Our New Line!

Products

SCISSOR DECK SYSTEMS

Scissor Deck Systems enable workers to safely access work areas with quick set-up continuous walkways.

​

Two or more Scissor Deck models may be bridged together with bridging planks either inline or on right angles.​ Handrails may be joined together with telescoping adjustable handrails for perimeter safety.

​

Used across a wide range of industries from aircraft maintenance to RV maintenance to construction and beyond, Scissor Deck systems increase your shops’ efficiencies by allowing workers to stay at their above ground tasks longer.

SYSTEMS

SCISSOR DECK 9000 SERIES

The 9000 Series is our most heavy-duty Scissor Deck to date. The 9000 Series features 4-sided safety orange powder coated handrails as shown in the photos to the right and a max deck height of 8'9".

​

Specifications:

  • max deck height to 8' 9"

  • 30" wide x 6' length deck

  • 47" wide fixed leg footprint

  • 77.5" min deck height

  • Includes 4 telescoping deck support stanchions with safety orange powder coating

  • Wheels: 6" smooth surface locking wheels or 10" locking pneumatic wheels

  • 10 height adjustment settings with 27" range

  • 129"L x 45" W footprint folded down.

​

The 9000 is also available as a powered version. Powered scissor decks have the option of extension ladder or adjustable stairway approach.

9000 Series

SCISSOR DECK 8000 SERIES

The 8000 Series is our second largest Scissor Deck to date, with a max deck height of 7'9". The 8000 Series offers options for 3-sided deck end, side entry handrail, and safety orange powder-coated handrails.

​

Specifications:

  • max deck height to 7' 9"

  • 30" wide x 6' length deck

  • 47" wide fixed leg footprint

  • 7' 6" (8" deck height increase) or 7' 10" (12" deck height increase) max deck height models

  • 5' 3"  or 5' 7" min deck height

  • Includes 4 telescoping deck support stanchions with safety orange powder coating

  • Wheels: 6" smooth surface locking wheels or 10" locking pneumatic wheels

  • 10 height adjustment settings with 30" range

  • 129"L x 45" W footprint folded down.

​

The 8000 is also available as a powered version. Powered scissor decks have the option of extension ladder or adjustable stairway approach.

8000 Series

POWERED SCISSOR DECK 8000 SERIES

The Powered version of our 8000 Series Scissor Deck, with a 30" wide by 8' long deck size. Available with extension ladder or height-adjustable stairway.

​

Specifications:

  • 2000 lb capacity worm gear powered cable lift

  • Powered by drill / driver - not supplied

  • 500 lb deck capacity for 2 workers

  • Height-adjustable to max deck height of 94"

  • 30" wide x 8' length deck

  • Powder coated handrails both deck sides with gates

  • Folding lower frames - for shorter length storage and transport footprint

  • Includes 4 telescoping deck support stanchions with safety orange powder coating

  • Wheels: 6" smooth surface locking wheels or 10" locking pneumatic wheels

  • Aluminum tube 6061 welded construction with 3x2 scissor frame sides

  • Type 1 (250 lb capacity) extension ladder OR 10-step height-adjusting stairway

  • Anti-slip deck surfaces

1 of 4 RV Manufacturing Systems supplied

Powered 8000
7000 Series

SCISSORDECK 7000 SERIES

The 7000 Series is a highly versatile and popular model used across the aircraft, RV, heavy truck and construction industries, and more.

Specifications:

  • 6' 10" max deck height

  • 20", 30", 40" wide x 6' length deck

  • 45" wide fixed leg footprint

  • 4' 7" min deck height

  • Wheels: 6" 500 lb capacity locking wheels or 880 lb cap. double pedal locking.

  • 13 height adjustment settings

  • Folds to 129" L x 45" W x 11" H

​

Removable lower frame legs now available for 6' compact stow deck length.

POWERED 7000

POWERED SCISSOR DECK 7000

The Powered version of our 7000 Series Scissor Deck, with a 30" wide by 6' long deck size. Available in 6' x 20" or 30" width.

​

Specifications:

  • 2000 lb capacity worm gear powered cable lift

  • Powered by drill / driver - not supplied

  • 500 lb deck capacity for 2 workers

  • Height-adjustable to max deck height of 80"

  • 30" wide x 6' length deck

  • Powder coated handrail options

  • Folding lower frames - for shorter length storage and transport footprint

  • Includes 2 or 4 telescoping deck support stanchions with safety orange powder coating

  • Wheels: 6" 500 lb capacity locking wheels or 880 lb cap. double pedal locking.

  • Aluminum tube 6061 welded construction

  • Type 1 (250 lb capacity) extension ladder

  • Anti-slip deck surfaces

SCISSOR DECK 6000 SERIES

The 6000 Series is a sturdy and versatile maintenance platform with applications across multiple industries but especially popular for aircraft maintenance.

​

Specifications:

  • max deck height to 6' with wheels or 6'9" with outriggers

  • 20", 30", 40" wide x 5' length deck

  • 45" wide fixed leg footprint

  • 3' 5" min deck height

  • Includes 4 telescoping deck support stanchions with safety orange powder coating

  • Wheels: 6" 500 lb capacity locking wheels or 880 lb cap. double pedal locking.

  • 12 height adjustment settings with 27" range

  • 109"L x 45" W footprint folded down

​

A powered version of the 6000 Series is now available.

Removable lower frame legs now available for 5' compact stow deck length.

7000 SERIES

The 7000 Series is a highly versatile and popular model used across the aircraft, RV, heavy truck and construction industries, and more. The 7000 Series features a max deck height of 6'10" and 10 height adjustment settings.

​

Specifications:

  • 6' 10" max deck height

  • 20", 30", 40" wide x 6' length deck

  • 45" wide fixed leg footprint

  • 4' 7" min deck height

  • Wheels: 6" smooth surface locking wheels or 10" locking pneumatic wheels

  • 10 height adjustment settings

  • Folds to 129"L x 45" W x 11" H

​

A powered version of the 7000 Series is coming soon.

6000 Series

SCISSOR DECK 5000 SERIES

5000 Series

The 5000 Series is a sturdy and versatile maintenance platform with applications across multiple industries. The 5000 Series features a max deck height of 5'.

​

Specifications:

  • max deck height to 5' with wheels or 5'10" with outriggers

  • 20", 30", 40" wide x 4' length deck

  • 37" wide fixed leg footprint

  • 3' min deck height

  • Wheels: 6" 500 lb capacity locking wheels or 880 lb cap. double pedal locking.

  • 9 height adjustment settings with 27" range

  • 90" L x 45" W footprint folded down

​

A powered version of the 5000 Series is coming soon.

4000 Series

SCISSOR DECK 4000 SERIES

The 4000 Series is a light, versatile mobile maintenance platform with applications across multiple industries. Its compact frame suits well with lower height tight work areas. The 4000 Series features a max deck height of 44".

​

Specifications:

  • max deck height to 44"

  • 20" or 30" wide x 4' length deck

  • 32" wide fixed leg footprint

  • 30" min deck heigh

  • Wheels: 6" smooth surface locking wheels

  • 6 height adjustment settings

  • 75"L x 11" W footprint folded down

​

A powered version of the 4000 Series is coming soon.

700 SERIES STAND

Scissor Deck Maintenance Stands feature spring-assisted manual lifts, a narrow frame design and an anti-slip perforated deck surface.



Scissor Deck Maintenance Stands offer many customizable options as well as enhanced versatility when used as part of a Scissor Deck System.

​​

700 Stand
lock pin handle
stand lock pin

700 Series Specifications:

  • 81" max deck height

  • 20" wide x 6' length deck

  • 54" min deck height

  • 135" x 45" x 8" folded down

  • Weight: 105 lbs stand only, 136 lbs with handrail & ladder

  • Removable handles for lifting unit and locking into closed position:

600 SERIES STAND

Scissor Deck Maintenance Stands feature spring-assisted manual lifts, a narrow frame design and an anti-slip perforated deck surface.



Scissor Deck Maintenance Stands offer many customizable options as well as enhanced versatility when used as part of a Scissor Deck System.

​​

600 Series Specifications:

  • 66" max deck height

  • 20" wide x 5' length deck

  • 36" min deck height

  • 112" x 45" x 8" folded down

  • Weight: 84 lbs stand only, 112 lbs with handrail & ladder

  • Removable handles for lifting unit and locking into closed position:

stand lock pin
lock pin handle
600 Stand
500 Stand

500 SERIES STAND

Scissor Deck Maintenance Stands feature spring-assisted manual lifts, a narrow frame design and an anti-slip perforated deck surface.



Scissor Deck Maintenance Stands offer many customizable options as well as enhanced versatility when used as part of a Scissor Deck System. â€‹

500 Series Specifications:

  • 55" max deck height

  • 20" wide x 4' length deck

  • 31" min deck height

  • 95" x 40" x 8" folded down

  • Weight: 67 lbs stand only, 90 lbs with handrail & ladder

  • Removable handles for lifting unit and locking into closed position:

stand lock pin
lock pin handle
400 Stand

400 SERIES STAND

Scissor Deck Maintenance Stands feature spring-assisted manual lifts, a narrow frame design and an anti-slip perforated deck surface.



Scissor Deck Maintenance Stands offer many customizable options as well as enhanced versatility when used as part of a Scissor Deck System. â€‹

400 Series Specifications:

  • 44.5" max deck height

  • 20" wide x 4' length deck

  • 27" min deck height

  • 81.5" x 37" x 8" folded down

  • Weight: 63 lbs stand only, 84 lbs with handrail & ladder

  • Removable handles for lifting unit and locking into closed position:

stand lock pin
lock pin handle
Scissor Deck Testimonials
GREAT INVESTMENT

— PETER KARIM,

BODY SHOP FOREMAN,

WESTERN STAR STERLING

We use it (7000 series system) for working on roofs of trucks and sides of trailers. All end dumps. Cement mixers. We do body work, welding, fitting, painting. It's great I love it . It's safe. It's a great investment.
